Description

Topp Pro X CS12A is an active powered DSP-processed loudspeaker for all types of PA applications. The high power 1600 Watt power provide high quality and high SPL for majority of the PA system requirement. The built-in DSP analyse and regulate incoming signal to ensure the optimum audio performance to be achieved. The DSP provides user 3 presets to custom tune the audio performance according to venue and occasions. The cabinets have been designed to provide a cost effective high grade solution while maintaining high quality cabinet construction. The 12” woofer and 1” neodymium driver combination provides excellent performance rivalling  those cabinets costing much more. This X CS12A system can be expanded with 2 slots for extension cards; USB Player (optional) and IP Control (optional).

Tech Specs

• Powered: Yes
• System type: Bi-amped with DSP processor
• Presets: 3; Flat, Music, User
• LF Driver Size:1 x 12", 2” Voice Coil
• HF Driver Size:1" NEO driver, 1” Voice Coil
• Power: 1600 W (Peak)
• Horn Coverage: 90H x 60V
• Inputs: 1 x XLR combo jack
• Outputs: 1 x XLR
• Frequency Range: 50Hz-20khz (-6 dB)
• Crossover Frequency: DSP at 1600 Hz
• Maximum Peak SPL: 125 dB
• Protection: Thermal / Overload / Digital Limiter / Compressor
• Enclosure Material: Polypropylene
• Mounting Options: Pole Mount, Floor Wedge, 4 x M10 Fly Points (optional)
• Optional Card Slot: USB Player, IP Control
