Put Your Best Vocal Tone Forward
VOICETONE T1 automatically reacts to your voice and applies studio-quality dynamics and EQ to bring out your most-exciting vocal tone. Now you can put a recorded sheen on your live singing – without the setup and adjustment of complex equipment normally required to achieve “that sound”.
It’s Just this Simple...
- Plug in your mic, plug your pedal into the mixer & set the gain
- Turn on the effect
- (That’s it)
Of course, you can always change the style or the amount of correction, but you shouldn’t need the manual – unless you’re making a fire!
Chain It
You can chain VOICETONE T1 to all of the other VOICETONE singles, mixing and matching effects to define your personal sound. It also works with DITTO MIC LOOPER, the pure looping pedal for singers and instrumentalists. Use the Singles Connect Kit (available separately) to mix and match up to 4 TC HELICON vocal effect pedals together conveniently, simply – and with less cable clutter than ever before.
Under The Hood
Beneath VOICETONE T1’s sturdy, die-cast metal case, you’ll be getting the same quality processing you’ve come to expect from our flagship VoiceLive® vocal processors. You’ll also find a clean, quiet mic preamp that rivals high-end touring mixers, plus studio-quality analog to digital conversion. There’s even a USB connection for firmware updates.
Unforgettable Tone
- Control multiple bands of EQ to reduce ‘muddiness’ and add brightness
- Add studio polish, reduce vocal peaks and unwanted T, S and D sounds
- Add warmth & fullness – without making your voice sound muddy
- Dedicated on-off switch and USB connection for updates
More Mic, More Control
You can completely control VOICETONE T1 from your mic – simply plug in a TC HELICON MP-75 microphone (sold separately). We call it Mic Control, and it allows you to command both the stage – and the audience!
Design
Size | Height: 5.4 inches (140 mm)
Width: 3.5 inches (90 mm) Depth: 2.3 inches (60 mm) |
Weight | Weight: 0.92 lb. (0.42 kg) |
Construction | Two part dies cast metal
Rubberized base |
Connections
Analog Inputs | Connectors, balanced: Mic.: XLR
Mic Input Level @ 0 dBFS: -42dBu to +1dBu EIN @ Max Mic Gain Rg = 150 Ohm: -126 dBu Mic input SNR: >104 dB Phantom Power: 24V (always on) Guitar Input impedance: 1 MOhm Guitar Input Level @ 0 dBFS: -7 dBU to 17 dBu Guitar Input SNR: >115dB Dynamic Range: >104 dB, 20 Hz to 20 kHz Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz |
Analog Outputs | Output Impedance, Bal./Unbal.: 200/100 Ohm
Output Full Scale: +1 dBu Dynamic Range: >104 dB, 20 Hz to 20 kHz Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz |
Control | USB for firmware and control
Mic Control using TC Helicon MP-75 Microphone or Sennheiser e 835 fx mic |
Safety And Regulations
Power | Power Supply (Supplied): 12V .4A
Power Consumption: 5.6W |
Safety | EMC – Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
Safety – certified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA |
Environment | Operating Temperature: 32°F to 122°F (0°C to 50°C)
Storage Temperature: -22°F to 167°F (-30°C to 70°C) Humidity: Max. 90 % non-condensing |
What's in the box? | Region specific power supply
USB cable User guide |
