Watch VOICETONE C1 at Work
Singer-songwriter Christine Havrilla adds intrigue to her song with some HardTune at 1:00 & renowned vocal coach Brett Manning shows off some of the wild possibilities of C1.
New Vocal Territory
VOICETONE C1 starts with a clean, transparent correction of your voice – just set the key and go – or use the guitar input. It ends with the wildly popular pitch-gliding HardTune effect. A twist of the gender knob really gets you sounding like an alien with some fascinating biological choices...
It’s Just this Simple...
• Plug in your mic, plug your pedal into the mixer & set the gain
• Turn on the effect
• (That’s it)
Of course, you can always change the style or the amount of correction, but you shouldn’t need the manual – unless you’re making a fire!
Chain It
You can chain VOICETONE C1 to all of the other VOICETONE singles, mixing and matching effects to define your personal sound. It also works with DITTO MIC LOOPER, the pure looping pedal for singers and instrumentalists. Use the Singles Connect Kit (available separately) to mix and match up to 4 TC HELICON vocal effect pedals together conveniently, simply – and with less cable clutter than ever before.
Under The Hood
Beneath VOICETONE C1’s sturdy, die-cast metal case, you’ll be getting the same quality processing you’ve come to expect from our flagship VoiceLive® vocal processors. You’ll also find a clean, quiet mic preamp that rivals high-end touring mixers, plus studio-quality analog to digital conversion. There’s even a USB connection for firmware updates.
Vocal Bending Gymnastics
1. Simple guidance of pitch correction with key, chromatic or guitar input
2. Control your attack from subtle correction to jagged HardTune
3. Adjust your vocal biology from male/deep gender to alien female
4. Dedicated on-off footswitch and USB connection for updates
More Mic, More Control
Beneath VOICETONE C1’s sturdy, die-cast metal case, you’ll be getting the same quality processing you’ve come to expect from our flagship VoiceLive® vocal processors. You’ll also find a clean, quiet mic preamp that rivals high-end touring mixers, plus studio-quality analog to digital conversion. There’s even a USB connection for firmware updates.
Design
| Size |
Height: 5.4 inches (140 mm)
Width: 3.5 inches (90 mm)
Depth: 2.3 inches (60 mm)
|
| Weight |
Weight: 0.92 lb. (0.42 kg) |
| Construction |
Two part dies cast metal
Rubberized base
|
Connections
| Analog Inputs |
Connectors, balanced: Mic.: XLR
Mic Input Level @ 0 dBFS: -42dBu to +1dBu
EIN @ Max Mic Gain Rg = 150 Ohm: -126 dBu
Mic input SNR: >104 dB
Phantom Power: 24V (always on)
Guitar Input impedance: 1 MOhm
Guitar Input Level @ 0 dBFS: -7 dBU to 17 dBu
Guitar Input SNR: >115dB
Dynamic Range: >104 dB, 20 Hz to 20 kHz
Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz
|
| Analog Outputs |
Output Impedance, Bal./Unbal.: 200/100 Ohm
Output Full Scale: +1 dBu
Dynamic Range: >104 dB, 20 Hz to 20 kHz
Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz
|
| Control |
USB for firmware and control
Mic Control using TC Helicon MP-75
|
Safety And Regulations
| Power |
Power Supply (Supplied): 12V .4A
Power Consumption: 5.6W
|
| Safety |
EMC – Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
Safety – certified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA
|
| Environment |
Operating Temperature: 32°F to 122°F (0°C to 50°C)
Storage Temperature: -22°F to 167°F (-30°C to 70°C)
Humidity: Max. 90 % non-condensing
|
| What's in the box? |
Region specific power supply
USB cable
User guide
|
