Compact Flagship UHF Wireless Microphone System – Uncompromising Performance, Ultimate Clarity

Designed as the top-of-the-line model in the IVA wireless microphone series, the PRO-UD2 Advance delivers superior audio quality, cutting-edge RF technology, and seamless user experience in a COMPACT body. Built for professionals who demand exceptional sound clarity and reliability, this system ensures that every performance, speech, or presentation is heard with absolute precision. Featuring True Diversity Antenna Reception, the system intelligently switches antennas, receiving and demodulation circuitry to avoid signal dropouts, ensuring rock-solid wireless performance. The impeccable audio balance across high, mid, and low frequencies provides natural, effortless voice reproduction, making vocals smooth and expressive. With four EQ presets, users can fine-tune their microphone’s tone, enhancing bass or treble to suit individual vocal characteristics. The built-in RF Spectrum Detector and Artificial Intelligent (AI) Scanning take the guesswork out of frequency selection—automatically analyzing and selecting the cleanest available RF channels for interference-free transmission. Pairing is effortless, with infrared synchronization or the innovative Shake-to-Sync feature for fast and hassle-free setup. The IVA PRO-UD2 Advance Compact is engineered for performers, speakers, and professionals who demand the best in wireless microphone technology—offering unparalleled stability, clarity, and ease of use

Tech Specs

• Main Frame Size: EIA Standard 1U
• Receiving Channel: Two channels
• Receiving Mode: CPU Controlled True Diversity + Pilot Identification Reception
• Frequency Stability: ±0.005%
• Carrier Frequency Range: 565 Mhz - 590 Mhz
• Total Frequency Channel: 100 CH
• Oscillation: PLL Synthesis
• Sensitivity: >95 dBm
• Bandwidth: 25 MHz
• Max. Deviation Range: ±5kHz
• S/N: >50 dB
• T.H.D: <1%
• Frequency Response: 70 Hz ~ 15 kHz ±3dB
• Transmitter Transmission Strength: 11 mW / 8 mW for handheld & bodypack
• Spurious Emission: -35 dBm
• Operating Distance: 50 meters in line of sight & low RF noise environment
• Antenna Interface: 2 x BNC
• Audio Interface: 6.3mm unbalanced audio output, XLR balanced audio output
• Max. Unit Stacking: 10 sets in low RF noise environments
• Power Supply: 12 VDC /1.25 A
• Battery: AA 1.5V for handheld & bodypack
• Battery Life: ~ 6 hours for handheld & bodypack
• Power Consumption: 180 mA for handheld & bodypack
• LCD Display: Frequency, CH, Battery, RF, AF, MUTE for Receiver, Frequency, CH, Battery for Handheld & Bodypack
• Dimensions (WxDxH): 210 x 42 x 180 mm
• Weight: 1.8 kg
• Packaging Dimensions (WxDxH): 480 x 71 x 340 mm
• Packaging Weight: 3 kg
