Overview

• Low mains current draw with proven IDEEA technology
• Networked control via IntelliDrive Controllerr℠touch-based GUI
• Ethernet network connection
• AES3 and analog inputs with redundant failover
• Link outputs for analog and AES3
• Software-configured Speaker Protect Limiter
• Fast network setup with auto-discovery and ID of amplifiers
• Four-channel input mixer

*Integrated DSP includes:

• 40 real-time, multi-slope parametric equalizers
• Adjustable high-pass and low-pass filters
• Input delay (up to 2 s)
• Output delay (up to 2 s)
• Crossover with multiple filter types
• 100 user-definable presets
• IPD LoadLibrary speaker presets
• Backlit display with navigation buttons and encoder for front panel setup
• Horizontal VU meters on display in operating mode
• Mute buttons on front panel
• Binding post and Neutrik speakON connectors
• Outputs may be connected through either one (NL-4) or both speakONs
• Universal power supply: 100 – 240 V at 50 or 60 Hz
