• Dual 48 channel personal monitor mixer compatible with Midas personal monitoring system hubs
• 12 stereo groups enable rapid creation and balancing of personal mixes from fully configurable stem groups
• Dual mix feature allows independent control of two complete monitor mixes
• Integrated SD card interface for stereo recording and playback of rehearsal sessions and performances
• Built-in stereo ambience microphone provides on-stage sound feed to remove sense of isolation with in-ear monitors
• Studio-quality reverb adds spatial ambience to personal in-ear mixes, independent from main console
• Remotely powered via direct AES50 connection from Midas hubs featuring Power over Ethernet (PoE)
• Separate DC power supply allows daisy-chaining of DP48 personal monitor mixers and use without any PoE hub
• Compatible with any 44.1/48 kHz AES50-equipped devices including Midas and Behringer digital consoles and I/O boxes
• Midas PRO SERIES and M32 console input channel labelling and colour information transmitted to DP48 personal monitor mixer via AES50 input channels
• AES50 return channels allow personal mixes to be sent back to the console or hub for connection to wireless IEM transmitters
• Remote operation up to 100 m via screened CAT5/5e cable
• Remote setup and control of DP48 personal monitor mixer via Midas hubs
• Full remote control of another DP48 when both connected to the same hub or used in daisy chain configuration
• High-contrast 2.4" colour TFT display screen provides clear overview of mix parameters, meters and group assignments
• Analogue stereo auxiliary input for local click track
• High power headphone output for use in all stage monitoring environments
• Fully adjustable limiter allows for safe monitoring levels within sound exposure limits
• Mounts securely on microphone stand with DP48MB adaptor (not included)
• Designed and engineered in the U.K.

Tech Specs

• Type: Dual Monitor Mixer
• Compatibility: Midas AES50 Hubs
• Number of Ports: 1 x In, 1 x Thru
• Connection Type: Locking Ethernet (AES50)
• Input Channels: 48 Channels, 12 Groups
• Analog Inputs: 2 x 1/4" (L/R aux in)
• Analog Outputs: 2 x 1/4" (A mix, B mix)
• Headphones: 2 x 1/4" (A mix, B mix)
• Data I/O: SD/SDHC Card Slot
• Form Factor: Stand Mount
• Power Source: Power over Ethernet / 24V DC power supply
• Height: 2.72"
• Width: 9.53"
• Depth: 6.46"
• Weight: 2.9 lbs.
• Manufacturer Part Number: DP48
