• 40-input channel, 25-bus rack-mountable digital mixing console for Studio and Live application
• 16 Midas-designed, fully programmable mic preamps for audiophile sound quality
• 17 Fully automated motorized 100 mm faders allow for instant overview, powerful scene management and DAW control
• 8 XLR outputs plus 6 additional line in/outputs, a phones connector and a talkback section with XLR mic input
• 32 x 32 channel USB 2.0 audio interface, with DAW remote control emulating HUI* and Mackie Control*
• iPad* and iPhone* apps for professional remote operation available free of charge—no host PC required
• High-resolution 5" day-viewable Color TFT for easy viewing of workflow components and parameters
• Main LCR, 6 matrix buses and all 16 mix buses each featuring inserts, 6-band parametric EQ's and full dynamics processing, plus 8 DCA groups and 6 mute groups
• Virtual FX rack featuring 8 true-stereo FX slots include high-end simulations such as Lexicon 480L* and PCM70*, EMT250* and Quantec QRS* etc.
• 40-Bit floating-point DSP features "unlimited" dynamic range with no internal overload and near-zero overall latency for mixing a total of 48 signals on 25 buses
• Powerful scene management for convenient handling of complex productions
• 48-channel Digital Snake ready* via AES50 ports, featuring Klark Teknik’s SuperMAC networking capability for ultra-low jitter and latency
• USB type-A connector providing file storage and uncompressed stereo recordings plus show presets and system updates
• Dedicated and easy-to-use channel strip section with direct access controls and graphic user interface for intuitive workflow
• Additional user-definable control section allows to set up short-cuts to your favorite views or parameters
• ULTRANET connectivity for Behringer's P16 Personal Monitoring System*
• Networked remote control via Ethernet for show setups with on-screen software editor
• Built-in expansion port for audio interface cards or digital networking bridges
• MIDI In/Out for remote scene recall or controlling other MIDI equipment
• Future firmware updates, incl. new FX “Plug Ins”, downloadable from behringer.com free of charge
• Rack mount brackets included for ultimate flexibility
• Designed and engineered in Germany

Tech Specs

• Type:Digital
• Channels:32
• Inputs - Mic Preamps:16 x XLR
• Phantom Power:32 x Channels
• Inputs - Other:2 x RCA (Aux), 6 x TRS (Aux)
• Outputs - Main:8 x XLR
• Outputs - Other:2 x RCA (Aux), 6 x TRS (Aux)
• Inputs - Digital:32 x USB, 2 x AES50 (32 via Optional Digital Snake)
• Outputs - Digital:32 x USB/Firewire, 2 x AES50 (32 via Optional Digital Snake)
• Aux Sends:16 x Aux Sends
• Send/Return I/O:6 x TRS
• Busses/Groups:25 Total (16 x Bus, Main LCR, 6 x Matrix)
• Channel Inserts:Virtual (Physical Assignable to AUX In/Outs
• Talkback:Yes
• Data I/O:Ethernet, USB, MIDI I/O
• USB:1 x Type B, 1 x Type A
• Computer Connectivity:USB (32 x 32)
• I/O Expansion Slots:1 x Slot (Includes 32x32 USB Interface)
• Headphones:2
• Faders:17 x 100mm (Motorized)
• EQ Bands:4-band Parametric EQ (6-band on Mix Bus)
• Effects:Yes
• Transport Controls:via Assign Section
• DAW Control:Yes
• Rackmountable:Yes
• Height:6.4"
• Depth:19.9"
• Width:19.3"
• Weight:25.1 lbs.
